Moisture Analyser MB120 - 120G X 0.001G





Application: Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing



Display: 4.3_ TFT color touchscreen display



Operation: Power cord (included)



Communication: RS232 with GLP/GMP data output, USB Host and USB Device (included)



Construction: Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover







Maximum capacity: 120 g



Readability: 1 mg/0.01%



Pan Size: (LxW) 90 mm



Dimension: (HxLxW)180mm x 355 mm x 211 mm



Net Weight: 5.23 kg



Heater Type: Halogen Lamp



Communication USB host x 2; USB device; RS232



Display: Full-Color 4.3 in Touchscreen WQVGA



Heating Profiles: Standard; Ramp; Step; Fast



In-use Cover: Included



Power: AC Adapter (included)



Moisture Range: 0 % - 100 %



Sample Size: 0.5 g - 120 g



Shut-Off Criteria: Manual;  Timed;  Automatic Preset Weight Loss/Time; Custom User Set Weight Loss/Time; Custom-User Set Moisture% Loss/Time



Temperature Range: 40ºC - 230ºC



Test Library: 100



Units of Measurement: Gram; %MC; %RG; %DC



Working Environment: 10ºC - 40ºC, 85%RH, non-condensing







MB120 Data Sheet



Quick Start Guide



Instruction Manual
